ETC Source Four Mini LED Gallery 3000 K (90+ CRI), Fixture Body with Shutter Barrel, Portable - Black

The Source Four CE Mini LED can go where no full-sized Source Four® has gone before. ETC’s 12W Source Four Mini LED features the same crisp optics, user-friendly functionality and sleek look of the legendary Source Four luminaire, but in a compact format at one- third it’s size.

The Source Four CE Mini LED has four field-angle choices and is available in a portable version,a ceiling-mount canopy version or a track-mount design. Surprisingly bright for its size, the Mini LED offers crystal-clear image projection and a bright, even field.

Features:

• Rugged, die-cast fixture body
• Interchangeable lens tubes permit selection of 19°, 26°, 36° and 50° field angles
• Unique, efficient optical system
• Long-life dimmable white LED source in two CRI values:
  • Source Four Mini LED Gallery: 90+ CRI
• Three-plane shutters
• Multiple accessories available for colour, gobo pattern, and filtering purposes
• Multiple mounting options: clamp, canopy and 3-circuit Eutrac (or Eutrac compatible track - consult vendor)
• ETC design colour black

Specifications:

• Physical:
  • Die-cast aluminium construction (A380 grade)
  • Fine-texture, high-temperature powder-coated paint
  • Steel yoke with 10.3mm diameter mounting hole
  • Rotating shutter assembly ±175°
  • E-size gobo pattern holder (included): 37.5mm with a 25.4mm image area
  • Stainless steel shutters in a tri-plane assembly
  • Fixed-beam angles to suit a range of throw distances
  • Tool-free tilt and beam adjustment
  • High-impact resistant, thermally insulated knobs and shutter handles
  • Captive accessory slot for pattern holder (included)
  • Dual captive accessory slots for media frame (included)
  • Portable:
    • Yoke-mounted LED driver in colour-matched enclosure
    • 1.8m power cable with UK or Schuko/NF connector
  • Black or white power lead
• Electrical:
  • Power at full intensity: 12W typical, 14W max
  • Input voltage 190-250V, 50/60Hz
  • Dimmable (forward and reverse phase)
  • Inrush current at 230V: 4A
  • CE compliant
• LED Engine:
  • Cree LED (90+ CRI)
  • Long-life: 35,000 hours L70 lumen maintenance
  • 3000K colour temperature options
• Optical:
  • 19°, 26°, 36° and 50° field angle Lens Tubes available
  • Projector-quality, high-contrast lenses
  • Beam edge continually adjustable hard to soft edge
• Thermal: 0°C to +40°C ambient operating environment
